| Categories | Board to Board Connector |
|---|---|
| Brand Name: | WCON |
| Model Number: | PMS-A-XX-XXX-XXAMX1 |
| Certification: | SGS/ROHS |
| Place of Origin: | China |
| MOQ: | 1000pcs |
| Price: | negotiation |
| Payment Terms: | T/T |
| Supply Ability: | 800000pcs |
| Delivery Time: | 15~25Day |
| Packaging Details: | Tray packing |
| Insulator Material: | PA9T+G.F,UL94V-0 |
| Rated Current: | Power 30A Signl 2.5A |
| Insulation Withstand Voltage: | Power 2500VAC/1min Signal 1000VAC/1min |
| Plasitc: | PA9T |
| TYPE: | Straight |
| port: | hong kong |
Power+Signal PSP A Type Straight Male(3+16+3)PA9T BK A=3.43mm Sel.30U"Au/Matte Sn,40/Tray,NW:11.964g.
| Insulator Material | PA9T+G.F,UL94V-0 |
| Terminal Material | Copper Alloy |
| Terminal Plating | Au/Sn Plated Over Nickel |
| Rated Voltage | 50V |
| Rated Current | Power 30A Signl 2.5A |
| Contact Resistance | Power 0.7MΩ Max Signal 2010mΩ Max |
| Insulation Resistance | DC500V PPWER 10000MΩ Min Signal 500MΩ Min |
| Insulation Withstand Voltage | Power 2500VAC/1min Signal 1000VAC/1min |
| Durability | 200 cycling |
| Power+Signal PSP A Type straight angel Male | |
| 1.PSP mixed power and signal distribution connectors designed to support high power applications, it also has the power and signal contacts, capable of simultaneous power allocation and power control in a connector | |
| 2.PSP mixed power and signal distribution connector can provide 1-20 power contacts and 0-148 signal contacts. The rated current capacity of each power supply contact is 48A; | |
| 3. power supply contacts and signal contacts can provide two levels of sequential matching, which can support up to three levels of power supply and signal sequence matching. |
Drawing:PMSXX-A-XX-XXX-XXAMX1.pdf
| Our Honor | |||||||||
| Dongguan WCON Hardware Electronics Co., Ltd located at Boye Ind. Park, ZhongnanZhong Road., Shangsha District, Chang'an Town, Dongguan City, Guangdong province, Who honored "National High-Tech Enterprise" "National Well-known trademark Enterprise""Guangdong Famous brand enterprise" "Guangdong Brand-name product enterprise",Dongguan "Observing contract & Valuing credit" enterprise, Member of The CECA-Connectors branch" and "Dongguan hardware Molding association", "The IPC- international electronic industrial connection Association member", Chang'an "Large Private Taxpayer" and "Outstanding Private Enterprise". |
|
