| Categories | Desktop SMT Pick And Place Machine |
|---|---|
| Brand Name: | Charmhigh |
| Model Number: | CHM-T36VA |
| Place of Origin: | Changsha,Hunan |
| Certification: | CE,FCC,RoHS,SGS |
| MOQ: | 1 set |
| Price: | price negotiable |
| Packaging Details: | export wooden box |
| Delivery Time: | within 15 days after full payment |
| Payment Terms: | T/T |
| Supply Ability: | 100sets |
| Dimensions: | 940mm×710mm×340mm |
| Transmission System: | Synchronous Belt+polished Rod |
| Mounting Speed: | 6000cph(optimal Without Vision Detection) |
| Control System: | External Computer Required (Windows) |
| Weight: | 39kg |
| Air Supply: | No External Air Supply Required |
| Power Supply: | AC220V (50Hz, Single Phase) /AC110V (60Hz, Single Phase); 300W |
| PCB Size: | 10mm×10mm～345mm×360mm |
| CHM-T36VA Specifications | |
| Dimensions | 940mm(L)×710mm(W)×340mm(H) |
| Weight | 39kg |
| Power Supply | AC220V (50Hz, single phase) /AC110V (60Hz, single phase); 300W |
| Air Supply | No external air supply required |
| Vacuum Generation | Built-in vacuum pump |
| Mounting Head Quantity | 2 |
| Mounting Speed | 6000cph(optimal without vision detection); 2500cph (optimal with vision detection) |
| Control Accuracy | 0.025mm |
| Component Type | 0402/0603～5050/SOT/SOP/QFP/QFN/BGA, etc. (resistor/capacitor/diode/triode/LED/IC, etc.) |
| PCB Thickness | 0.6mm~3.5mm |
| PCB Size | 10mm(L)×10mm(W)～345mm(L)×360mm(W) |
| PCB Conveying | Manual operation |
| Nozzle Change | Manual operation |
| Control System | External computer required (Windows) |
| Drive System | X&Y-axis driven by stepping motors in the way of closed-loop control realized by encoder; Z-axis capable of reset detection;all motors adopting flexible S-curve acceleration and deceleration; tape puller automatic reset supported |
| Transmission System | Synchronous belt+polished rod |
| Feeding System | 29 tape feeding stacks(8mm:22,12mm:4,16mm:2,24mm:1；customization supported), 14 preset general IC stacks, work surface custom IC trays and stick feeder supported |
| Vision System | Up-looking camera for component automatic calibration (component size applicable: 22mm×22mm); down-looking camera for PCB calibration via Mark Point and component positioning |
Desktop SMT Pick And Place Machine Technical Support and Service
At XYZ, we provide comprehensive technical support and service for our Desktop SMT Pick And Place Machine. Our experienced technicians are available to answer your questions and resolve any issues that you may have.
We offer a wide range of services including:
Our team is committed to providing you with the highest quality of service and support. If you have any questions or concerns about our Desktop SMT Pick And Place Machine, please do not hesitate to contact us.
|
