4200x2600mm CNC Glass Cutting Equipment For Floating Glass Processing

Categories CNC Glass Cutting Machine
Brand Name: Jinan Lijiang Glass Machinery
Model Number: Lijiang Glass Cutting Machine
Certification: CE & ISO9000
Place of Origin: China
MOQ: 1 set
Price: Discussible
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 15 sets per month
Delivery Time: 5-8 working days
Packaging Details: Wooden Cases Package
After-sales service provided: Video technical support
Condition: New
Voltage: 380V 50HZ
Power(w): 3kw
Glass thickness: 2-25mm
Warranty: 1 Year
Name: mini cnc glass cutting machine
Control system: CNC Control
Color: Customers' Request
Cutting accuracy: ±0.5mm
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

4200x2600mm CNC Glass Cutting Equipment For Floating Glass Processing

CNC Automatic Glass Cutting Machine Glass Cutting Production Line


for Floating Glass Processing


Brief Introduction:


1. Equipped with 6 sets of imported cutter wheels and a set of setting tool.

2. A set of stability voltage power supply.

3. A set of best optimized software.

4. A set of computer operating system (including a set of computer and cutting software)



Mechanical:


1. The material of the tabletop: Metal tabletop(deformation will not happen)(The smoothness≤±0.2mm/m)

2. Rack/Guides: Imported from Japan and switzerland.

3. Transmission belt/Transmission belt wheels: Barbieri in Italy.

4. Cutter wheels/cutter holder: Samsung in Japan.

5. The tabletop: Industrial blankets imported from Korea (color in black).

6. Turret: It use the pneumatic pressure and the spring pressure at the same time to make the cutting best.



Software:


1.Special cutting soft(It can be used under Windows System).

2.There is a graphic library with hundreds of shapes which is convenient for drawing and operating.

3.There is also a set of Auto CAD drawing software.

4.The optimized software can be selected(Enter the size of the sheet glass directly, then it can cut the glass automatically and it’s not necessary to cut by using CAD drawing).

5.There is a function of auto correcting which can make the cutting accuracy high.

6.There is also a selecting function of cutting path.

7.There is also a function of origin point correcting.

8.Operating Entering: Key board and mouse.



Item.
Input Voltage380V/50Hz~60Hz/3 Phases
Power14KW
Air pressure0.4-0.8 Mpa
Cutting speed0-210m/min
Sucker quantity9 pieces(3 sucker for every arm)
Loading time20-50s
Vaccum pressure-70~-90kpa(can be adjusted according to glass thickness)
Processing thickness2.5-19mm
Automatic label(yes/no)yes
Loading moving controlRemote control
Sucking loading weight500kgs
Cutting size4200x2600mm
Overall size4600*3250*1500mm
Breaking table size4300*2700*900mm
Working table height900mm
Weight4900kg
