Carton Duplex Paper Board Making Machine 300m/Min Recycled Coating Paper Machine

Paper and carton recycled coating paper machine

Description

This paper and carton recycled coating paper machine is high configuration machine. It's specially design and produced to make high level coating paper.

Wire section is one of the main important parts of this coating paper machine, here we briefly introduce the wire section.The 4ply

wire section is composed of top wire forming device, wire table, breast roll and landing device, dewatering element group, wire guide roll, doctor, high/low pressure spray pipe, flushing spray pipe, tensioner, corrector, white water pan, wire drive roll, vacuum couch roll, edge squirt, walking board and so on. All rolls in wire section correct dynamic balance and balance grade is G1.6. Paper dryness after wire section can reach ≥ 22%. The wire section changes the wire by cantilever type, and the tension of the wire section is calculated according to 8KN/M. All roll bearings in the wire section are lubricated with grease. The fastener of the wire section is high quality stainless steel SS304.

Wire section parameters:

Quality warranty:

Quality assurance time for all mechanical equipment of this machine: 12 months after normal operation. Bearing and rubber rolls quality assurance time: 6 months after normal operation. During the quality assurance time, any equipment quality accidents caused by non-operational errors shall be the responsibility of the supplier.

Qinyang PingAn Light Industry Machinery Co., Ltd is one of the member companies of China paper making machinery association. We are a large paper making equipment enterprise integrating technology research & development, design, manufacturing, and marketing services.

Founded in 1985, the company established a large-scale standardized joint-stock enterprise according to the modern enterprise mechanism in 2006, and now has 178 employees, including 24 engineers and technicians, and 8 senior engineers from Xi'an Walmet. Our company is located in Li Village Industrial Zone, Qinyang City, Henan Province, China, covering an area of 6000m², and has 1 R&D department, 8 modern manufacturing workshops, 1 quality inspection center and has more than 50 sets of large and medium-size equipment with a series of functions, such as scientific research, design, production, testing, assembly and commissioning. The company has passed the ISO9001:2000 international quality management system certification and enjoys the right of import and export.

Our company's main product is large size paper making machine. The largest paper machine width we produce reaches 6000mm, working speed of 700m/min. The main production lines include packaging paper production lines with an annual output of 20,000-2,000,000 tons, cultural paper production lines with an annual output of 10,000-100,000 tons, tissue paper production lines with an annual output of less than 20,000 tons and various special paper production lines. Our company serves paper making enterprises, including plant design, production process, overall design, equipment processing, installation and debugging, worker training, after-sales service and so on.

With the principle of honest management, fine management and high quality service, our company has developed rapidly in recent years, and has developed a safe operation mode, which makes all kinds of papermaking equipment put into the market of domestic and abroad and received good comments from our customers.
