| Categories | PVC Pulverizer Machine |
|---|---|
| Brand Name: | BEISU |
| Model Number: | MF-800 |
| Certification: | ISO |
| Place of Origin: | CN |
| MOQ: | >=1 Sets |
| Price: | $10,000.00 |
| Supply Ability: | 200 Set/Sets per Year |
| Packaging Details: | Film packing or wood package as customer requirements |
| Output (kg/h): | 500 - 600kg/h |
| Feeding Size (mm): | 8 - 10mm |
| Output Size (mesh): | 20 - 80 mesh |
| Power (kW): | 45 |
| Range of Spindle Speed(r.p.m): | 2900 - 3700 r.p.m |
| Type: | Pulverizer |
| Voltage: | 220V/380V/415V/440V |
| Dimension(L*W*H): | 2000mm*2800mm*3200mm |
| Weight (KG): | 2000 KG |
| Raw material: | PVC |
| Motor power: | 90Kw |
| Material blade: | High alloy steel |
| Blade type: | Disc |
| Off fan blower motor power: | 1.1Kw |
| Fan blower motor power: | 11Kw |
| Bearing brand: | NSK |
| OIL filling system: | Oil pump |
| Dust collection type: | Bag |
| Contactor brand: | SIEMENS |
| Port: | SHANGHAI or NINGBO PORT |
| Company Info. |
| Zhangjiagang Beisu Machinery Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
The disc diameter of the MF series disc mill is 300 to 800 mm.
These plastic shredders are high-speed, precision grinders used to
process medium-hard, impact-resistant and fragile materials. The
pulverized material is introduced through the center of a
vertically fixed grinding disc, which is mounted concentrically
with an identical high-speed rotating disc. The centrifugal force
brings the material into the grinding zone, and the resulting
powder is collected by a blower and cyclone system. Depending on
the application, the machine can be equipped with an integrated
grinding disc or grinding section.
The plastic shredder is mainly composed of a motor, a disc blade, a
feed fan, a vibrating screen, and a dust removal system.
Some accessories can be selected according to the needs of
customers, such as converters, vacuum feeders, screw feeders,
magnetic nets, metal separators, chillers, pulse dust collectors,
weighing packaging machines, etc.
Technical features of hdpe pulverizer grinding equipment plant:
1. New type grinding disc design, high quality, strong wear
resistance, grinding disc life is twice that of ordinary grinding
discs.
2. Newly designed professional bearings, high speed. At the same
time, only one drive motor is used to ensure efficient grinding and
collision, which greatly saves the time of machine operation and
engineering control.
3. Easy to install and maintain, just open the door for cleaning.
4. The whole grinding process is sealed and there is no dust
leakage.
5. Fully automatic design, automatic feeding, discharging and
sorting.
6. The gap adjustment is simple, just use feeler gauge and
adjusting bolt to fine-tune.
7. The mill adopts a water-air dual cooling system.
8. Abundant optional accessories, professional solutions can be
made according to the customer's budget and processing
requirements.
Technical of hdpe pulverizer grinding equipment plant:
Model | SMF-400 | SMF-610 | SMF-800 |
Blade disc size | 400mm | 610mm | 800mm |
Blade Disc quantity | 2 pieces | 2 pieces | 2 pieces |
Shaft rotary speed | 4500 rpm | 4200 rpm | 3700 rpm |
Main motor power | 30kw | 45kw | 55kw |
Blower power | 3kw | 5.5kw | 7.5kw |
Flow valve power | 0.75kw | 0.75kw | 1.1kw |
Powder size | 10-100mesh | 10-100 mesh | 10-100 mesh |
Cooling method | Air cooling & water cooling | Air cooling & water cooling | Air cooling & water cooling |
Capacity | 150kg/h (PE) 80kg/h (PP) 20kg/h (PE) | 250kg/h (PE) 160kg/h (PP) 350kg/h (PE) | 350-400kg/h (PE) 200-250kg/h (PP) 500kg/h (PE) |
Machine size | 2500*2000*3000mm | 2800*2300*3000mm | 3200*2800*3200mm |
|
