| Categories | Optical Fiber Fusion Splicer |
|---|---|
| Brand Name: | Fujikura |
| Model Number: | 88S |
| Certification: | CE/ROSH/IOS9001 |
| Place of Origin: | Japan |
| MOQ: | 1 |
| Price: | Negotiation |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 500sets |
| Delivery Time: | 5-7 working days |
| Packaging Details: | Stander packing |
| Product name: | Fiber fusion splicer |
| No. of Fiber: | 1. |
| Return loss: | ≥60dB, >> 60 dB |
| Splice time: | 7 to 9sec |
| Battery: | 6,380mAh |
| Capacity: | Approx.300 splice and heat cycles |
| heat mode: | 30 heat mode |
| splice mode: | 100 splice modes |
| Magnification: | 200 to 320x |
| Cladding diameter: | 80-15μm |
| LCD monitor: | TFT5 inches with touch screen |
The faster automated features of the 90S(88S) fusion splicer reduce
installation times.
The fiber retention clamps support the automated operations. When
the sheath clamps open automatically after splicing, the fiber
retention clamps gently hold the spliced fiber to keep it from
flying out. The retention clamps release when the fiber is lifted
by the operator.
01.
Core Alignment Technology The 90S fusion splicer has high precision lenses which provide accurate core to core alignment regardless of core-cladding concentricity error. Also, the lenses allow the splicer to discriminate between fiber types.
02.
Advanced Image Processing Technology The 90S possesses advanced image processing technology which analyzes the profile of the fiber image as a brightness pattern. The 90S finds the true core position and achieves the consistent lower splice loss.
01.
03.
Fiber Discrimination Function The 90S fusion splicer automatically identifies the optimum arc discharge parameters in accordance with the fiber type.
01.
Automatic Blade Rotation The 90S fusion splicer and CT50 fiber cleaver are enabled with wireless data connectivity. This capability allows automatic cleaver blade rotation when the splicer judges the blade is worn. Also, the 90S fusion splicer can connect to two CT50s simultaneously.
| Fibre Count | Single |
| Cladding diameter | 80 to 150m |
| Coating diameter | 100 to 1000m |
| Applicable fibers | SM MM DS NZ-DS EDF |
| Fiber cleaved length | 8-22mm (standard) |
| Splicing mode | Auto & Manual |
| Average splice loss | 0.02dB(SM) 0.01dB(MM) 0.04dB(DS) 0.04dB(NZDS) |
| Return loss | ≥ 60dB |
| Environment conditions | Environment conditions: -25~+50C (operation temperature), 0~95%RH (hu |
| Protection sleeve length | 20mm 40mm 60mm |
| Product Keywords | optical fiber fusion splicer machine priceShineway Tech fiber splicing machine |
Color LCD monitor & 256 magnification
Compact & Light weight
Reversible monitor with control panel on each side Max. wind
velocity of 15m/s.
8 Sec. splice time, 40 Sec. tube-heat time Simultaneous X and Y
views
Large capacity internal battery
SYSTEM TEST ensures the best working condition User programmable
Auto check fiber end face
Auto calibrate parameters
Store 8000 groups of splice results Multiple language options
|
