2 Feet Linear Explosion Proof LED Lights 100-277V Super Brightness

Categories Explosion Proof LED Lights
Brand Name: CODT
Model Number: CODT-EXR18600
Certification: ATEX
Place of Origin: SHENZHEN
MOQ: Negotiable
Price: negotiable
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500pcs per day
Delivery Time: 5-20 working days
Packaging Details: Standard packing
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

2 Feet Linear Explosion Proof LED Lights 100-277V Super Brightness

2 feet LED Explosion proof linear fixture high efficacy LED Super brightness


Features

High efficacy LED Source with long lifespan>100,000 hours

5-year performance warranty

Low THD around 15%,Less interference 5KV Surge Protection

Robust aluminium housing and strong tempered glass Vibration and shock resistant

Low maintenance


Application

Oil&Gas Exploration

Drilling

Oil Refinery

Petrochemical Plant

Power Plant

Pharmaceutical Plant


Parameters


Electrical&photometic Features
Luminaire Efficacy:140lm/W
Lifespan:>50,000 hours
Operating Voltage:100-277 VAC
141-392VDC
36 VAC
24VDC/24VAC
Power(W):18/36/48/56/72/96
Frequency:50/60Hz
Power Factor:0.98
THD:15%
Insulation Class:
Surge Protection:5KV
LED Driver:Over voltage protection short circuit protection

Mechanical Features
Length:600mm900mm1200mm
Weight:6.9Kg9.2 Kg11.5Kg
Size:600X132X72mm900X132X72mm1200X132X72mm
Ambient Temperature:-20-+55
Connecting Terminals:3*1.0-4mm²(L+N+PE)
Available cable :Outer diameter φ7-φ14mm
Cable Entries:2 XM20*1.5 (M25*1.5 are optional)
Earthing Protection:M4 (Internal & external earth bolts)
IP Code:IP66
Enclosure Material:ADC12+PC
Enclosure Colour:Yellow RAL1026(optional Grey RAL7040)
Coating:Epoxy powder coating
Exposed Fastener:Stainless steel
Protective Cover:Tempered glass,Stand 7J impact
