N+L Wire, AC100-240V, 50/60Hz
Max Load Current: 10A Total
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
2. Tuya WIFI +RF433 (Without Neutral Wire) Version: No Neutral Wire, has Capacitor
90-130V AC, 60Hz or 200-240V AC, 50Hz (only choose one, pls remark when place order)
Max. current: 2.5A/Gang; Total 2.5A
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
3. Zigbee Version:
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
3. Zigbee Version:
Universal Wiring, "Live+Neutral Wire" & "Without Neutral Wire (No
Need Capacitance)" both are ok. AC100-240V,50/60Hz 220V: 3-600W(INC), 3-120W(LED,CFL) 110V:
3-300W(INC), 3-120W(LED,CFL)
Need work with Zigbee Gateway
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
4. Tuya Bluetooth Mesh Version
4. Tuya Bluetooth Mesh Version
Voltage: 90-250V AC, 50/60Hz Max. Current: 10A/Gang; Total 10A
【Short distance control】Blue tooth control distance max is around
30 meters. You can control the Blue tooth switch on APP within 30
meters without network.
【Long distance control】Above 30 meters. For example, if you wanna
control the home switch in your office, in another city, or when
your are in business trip etc, then you need add a blue tooth hub
to work with Blue tooth switch for long distance control (No
distance limitation) on APP with network.
