5CV-D Five Hole Manual Control Valve With PTO Function For Five Hole Dump Truck Control Valve And Five Fole Combination Control

Product Description:

5CV-D Five Hole Dump Truck Control Valve with PTO Function Aluminum alloy

Product Features

1.Body Material: Aluminum
2.Seal Material: HNBR
3.Working Pressure: 0.5-12 Bar
4.Ambient temperature: -55℃-180℃
5.Port Size: M10*1
6.Automatically locked in stop and fall position
7.Transposition clearly
8.Able to coordinate with the Pneumatic control valve
9. Small Operating force
10.Simple operation
11.Easy to install
12..Long service life

Description

1.Seal Material: HNBR
2.Working Pressure: 0.5-12 Bar
3.Ambient temperature: -55ºC-180ºC
4.Automatically locked in stop and fall position

Applications:

The dump truck/dump truck controls the lifting, lowering, mid stop, and floating of the cargo box. High reliability and large flow rate are required to cope with heavy loads and harsh working conditions.

The garbage compactor controls the compression mechanism circulation, filling device lifting, garbage bin lifting, etc. The action may be more complex, requiring the valve to respond sensitively and have good sealing performance.

Truck mounted cranes/lifting transport vehicles may be used to assist in the extension and retraction of support legs or certain hydraulic functions of the crane.

Special device control for sanitation vehicles used in sprinkler trucks, suction trucks, and other equipment.

Agricultural and mining machinery are used for large-scale agricultural dump trucks, mining wide body dump trucks, etc., with extreme working conditions, requiring extremely high pressure resistance and durability of valves.

Special operation platform controls the takeoff and landing of maintenance platform and lifting platform. Require stability and safety locking function

Support and Services:

The Product Technical Support and Services for the Hydraulic Control Valve product include:

- Installation assistance and guidance

- Troubleshooting support for any operational issues

- Maintenance recommendations and schedules

- Repair services for damaged or malfunctioning valves

- Product training for users and maintenance personnel

Packing and Shipping:

Product Packaging for Hydraulic Control Valve:

The hydraulic control valve is carefully packed in a sturdy cardboard box to ensure its safety during transportation. The box is labeled with product information and handling instructions for easy identification.

Shipping Information:

Orders are typically processed within 1-2 business days. The hydraulic control valve is shipped using a reliable courier service to ensure timely delivery. Customers will receive a tracking number to monitor the status of their shipment.
