Anti Slip Fixed Hydraulic Scissor Lift Table Elevator Platform 3000kg 2m For Loading Bays

Categories Hydraulic Scissor Lift Table
Brand Name: HAOXIANG BRAND
Model Number: SGJ3-2
Certification: CS/ISO
Place of Origin: GUANGDONG,CHINA
MOQ: 1 unit
Price: USD 1500-2500/UNIT
Payment Terms: T/T
Supply Ability: 2000 units per year
Delivery Time: 7-15 working days
Packaging Details: Naked packaging
Color: Yellow
Platform Size: 1300×1800mm
Load Capacity: 3000kg
Lifting Height: 2m
Scissor Type: Single Scissor
Warranty: 1 Year
Product Name: Fixed Scissor Lifting Platform
Country of Origin: Made in China
Control Mode: Hydraulic
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Anti Slip Fixed Hydraulic Scissor Lift Table Elevator Platform 3000kg 2m For Loading Bays

Hydraulic Fixed Scissor Lift Table with 3000kg Capacity, 2m Platform Height, Non-Slip Surface, Ideal for Loading Bays


Designed for permanent installation, this scissor lift features a compact, low-profile frame that can be fixed directly onto the factory floor or placed in a pit for flush mounting. Its hydraulic system delivers smooth and steady lifting, controlled by a simple push-button pendant. Optional foot controls or remote wireless control can also be provided. The lift’s steel platform features an anti-slip surface to prevent cargo shifting during operation.


Technical Parameter
Specifications, sizes and colors can be customized according to customer requirements
ModelRated load (kg)Lifting stroke (mm)Maximum height (mm)Lower height (mm)Table size (mm)Lifting timeMotor power (kw)
SJG1-1.71000170021504502500×2000203
SJG10-1.710000170025008004000×20003011
SJG3-43000300036506501500×6000405.5
SJG1-41000400046006003100×5000604
SJG2-52000500059009007000×3000605.5
SJG3-630006000700010006000×5000707.5
SJG5-1.75000170023506506000×2000407.5
