ne-step method represents a cutting-edge manufacturing technology that has emerged relatively recently. This technique is applicable for both hose insulation and hard pipe insulation. However, the one-step PERT insulation pipe production line cannot achieve the required production standards using conventional extrusion equipment. Consequently, specialized design is essential for the extruder's screw and barrel, the pipe mold, as well as the sizing and cooling systems. Within merely two years, Huashida Company successfully overcame 130 technical challenges and established China's first independently developed one-step PERT insulation pipe production line, which holds independent intellectual property rights.

Furthermore, Huashida Company has successively developed standard PERT insulation pipes and fiber-reinforced PERT insulation pipes. These products are categorized into two types based on their appearance and performance characteristics: flat-wall insulation pipes and corrugated insulation pipes.

1. Significantly reduce costs
2. Automated production
3. It avoids the limitation on the length of the insulation pipe (very long can be produced).
4. The hose can be directly buried and laid underground and requires a smaller trench
5. It has excellent mechanical properties
6. It ensures the sealing performance and chemical corrosion resistance during use, and the working pipe is not oxidized.
7. Easy to transport, move and store.

Process Flow

Up carrier pipe--pulling up to line--pipe catching connect--transport forward---put into seal &cover film device--foaming--foam curing ---PE cover extruding--vacuum sorb -- spray cooling--checking splice--cutting splice--off-pipe--down off pipe

Equipment components:
-- Plastic pipe upload table
-- Plastic pipe pulling device
-- Transfer Straight V wheel
-- Crawler-type push machine
-- Far infrared heating device
-- Pipe centering correction system
-- Foaming machine system
-- Over molding system
-- Automatic feeding machine
-- Hopper dryer
-- Extruder
-- Spray cooling water tank
-- Cutting Machine
-- Stacking table
-- Control System

Huashida's continuous PERT insulated pipe pipes are ideal for a wide range of applications, including district heating, cooling systems, oil and gas pipelines, and industrial piping. Their superior insulation, anti-corrosion properties, and long service life make them the preferred choice for modern, sustainable piping systems.

Qingdao Huashida Machinery Co., LTD, is a manufacturer of series of plastic pipe machines, municipal pipe machines, pipe insulation&anticorrosion machines, and pipe jointing&anticorrosion materials, with 21 years of production experience.
Our main products are:
1. HDPE jacket pipe for pre-insulated pipe Production Line
2. Rigid pre-insulated pipe Production Line
3. Flexible pre-insulated pipe(PERT) production line
4. Steel pipe FBE/2LPE/3LPE anti-corrosion coating line
5. Steel pipe derusting line
6. PE pressure pipe/Water Gas supply pipe production line
6. PP/PE plastic board/sheet/geomembrane production line
7. NBR PVC Thermal insulation tube/plate production line
8.Pipeline anti-corrosion materials and instruments: heat shrink joint coating sleeve, electro-fusion weldable joint sleeve, portable welding gun(extruder), PE PP welding rod.
We have been working with more than 400 overseas customers and exporting our products to Kazakhstan, Uzbekistan, Iran, Turkey, Russia, Nigeria and other countries.
