Single Phase Pad Mounted Transformer 125Kva 12470V Electrical Power Transformer Factory Price Meets ANSI/IEEE CSA Standards

Single Phase Pad Mounted Transformer 125Kva 12470V Electrical Power Transformer Factory Price Meets ANSI/IEEE CSA Standards

WINLEY 125 kVA pad mounted transformer meets/exceeds DOE 2016 efficiency ratings with UL/cUL listed. The WINLEY Transformer team possesses extensive experience in transformer projects within the North American market. Their service offerings are highly adaptable to suit your specific 100 kVA Transformer requirements.

Single Phase Pad Mounted Transformer Main data

The 125 kVA transformer features a compartmental design that strictly complies with IEEE Std C57.12.28 standards. Housed within its robust tank are separate high-voltage and low-voltage cable termination compartments, strategically aligned side by side on one side of the tank for optimized functionality and accessibility.

Drawing

The high-voltage compartment is equipped with advanced components, including two internally interconnected high-voltage bushing wells with inserts, a 4-position loadbreak switch for safe circuit interruption, a 5-position tap changer switch for voltage regulation, and a bayonet fuse for reliable overcurrent protection. Adjacent to it, the low-voltage compartment is outfitted with three stud low-voltage bushings for efficient power transmission and an oil level gauge to monitor the transformer's operational status, ensuring seamless and safe performance.

Specification

Production process

FAQ

1. Q: Can I have a sample order?

A: Yes, we welcome sample order to test and check quality.

2. Q: What is the lead time?

A: Mass production time 15-25 days.

3. Q: How long is the warranty?

A: 24 monthes from B/L. If there are any accessory problems,just provide the photos of damaged accessory,then we will provide free service. According to the number of products,we will provide easily damaged accessories for free. we also can provide technical support if you need.

4. Q: Is OEM/ODM available?

A: Yes,it is! We are manufacturer with our own R&D team, we can customize products according to customer's drawing or requirements.

Customized services:

a. Customized color and special function.

b. Customized box.

c. Print customer's logo.

d. Your other ideas about product, we can help you design and put them into production. The above customized services must be confirmed before production.

5. Q: How to control the products quality?

A: Our company owns the core technology ,all kinds of products hold CE certificate. We have professional engineers. Workers are strictly required to make products according to the drawings. Each process has technical instructors.The QC supervisors will regularly inspect the production. We will do products performance tests during production, and comprehensive quality tests when the products is completed.

WINLEY is located in Xiamen, China. We are specialized in manufacturing all kinds of transformers, voltage stabilizers, voltage regulators, etc. The products are widely used in industrial machinery, new energy, power generation, power supply, coal, metallurgy, petroleum, chemical, construction, port, airport, railway transportation, urban infrastructure, and other areas.

With more than 17 years experience, WINLEY always adhere to the route of "Integrity makes brand,quality wins the market"! We have a professional R&D team, a quality control team, scientific production management system and comprehensive customer service system.

WINLEY holds ISO 9001:2015 quality management system certification, All products have approved by CE certification, we can also apply for UL(Authorized by partner), SASO, SONCAP, etc. according to customer requirements.

WINLEY products are sold to Europe, North & South America, Oceania, Asia and Africa, more than 100 countries and regions in the world are using WINLEY products. Products’ quality and technical service are recognized by all customers around the world, and we have cooperative distributors in some countries.

And we will continue to carry forward the integrity of compliance, scientific and technological innovation, win-win cooperation spirit, provide quality products and comprehensive service to all partners, and work hard for the development of the world’s green electrical power.
